Showing 17–20 of 20 results
-
Product parameter table
Standard: External power supply type is simple and efficient, with high reliability and low equipment maintenance and operation costs.
Product model QE-106G
Processing capacity 180-400t/h
Main engine power 110kw
Total power 135kw
Equipment size (length*width*height) 14500*3100*3600mm
Iron remover 4kw
Feed hopper 6kw
Main belt 15kw
Feed port size 1060*750mm
Feeding capacity 400/t
Hopper volume 6m3
Total equipment weight 32t
Maximum feed size <700mm (recommended)
-
Product parameter table
Product model QY-HP300G
Processing capacity 150-230t/h
Host power 250kw
Total power 298kw
Equipment size (length * width * height) 16800 * 3380 * 3680mm
Feed belt 11kw
Excessive material reflux of 3kw
Main belt 15kw
Feed inlet size 1078mm
Return belt 5.5hw
Finished belt 7.5hw
Hopper capacity 5m3
The total weight of the equipment is 42t
Vibration hanging screen 6kw
Maximum feed particle size<250mm (recommended)
-
Product parameters
Processing capacity 180-320t/h
Screen box power 18kw
Total power 53kw
Transportation dimensions (length * width * height) 14800 * 3630 * 3650mm
Finished belt 1 5.5kw
Finished belt 2 5.5kw
Finished belt 3 5.5kw
Sieve belt 7.5kw
Feeding capacity 300t/h
Sieve box size 7500 * 1800mm
Feed conveyor 11kw
The total weight of the equipment is 28t
-
GS-1035 chute size: 1000-3450mm, maximum feed particle size: 450mm, processing capacity: 200-300mm, motor power: 15t/h, double amplitude: 4-10kw, weight: 3.5t
GS-1149 material trough size: 1100-4900mm, maximum feed particle size: 500mm, processing capacity: 300-400mm, motor power: 15t/h, double amplitude: 4-10kw, weight: 4.5t
GS-1159 material trough size: 1134-5900mm, maximum feed particle size: 550mm, processing capacity: 450-550mm, motor power: 22t/h, double amplitude: 4-10kw, weight: 5.35t
GS-1560 material trough size: 1500-6000mm, maximum feed particle size: 800mm, processing capacity: 600-800mm, motor power: 37t/h, double amplitude: 4-10kw, weight: 7.05t
