Crawler Mobile Cone Crusher QY-HP300
Product parameter table
Standard: External power supply type is simple and efficient, with high reliability and equipment maintenance
Product model QY-HP300
Processing capacity 150-230t/h
Main engine power 250kw
Total power 298kw
Equipment size (length * width * height) 16850*3650*3800mm
Feed belt 11kw
Return material transition belt 3kw
Main belt 15kw
Feed port size 1078mm
Return material belt 5.5hw
Return material belt 5.5hw
Hopper volume 5m
Total equipment weight 48t
Vibration hanging screen 6kw
Maximum feed size <250mm (recommended)
Description
Advantages and Features
The main crusher is highly efficient and wear-resistant
The special crushing wall and mortar wall design, supplemented by the curved cavity and hydraulic cavity clearing system, improves the crushing efficiency and effectively reduces the loss of wearing parts.
Automatic crushing control system
The ACS fully automatic crushing control system is adopted to quickly respond to iron (overload) and automatically release the reset protection to ensure continuous, stable and efficient production. Intelligent continuous feeding
Intelligent system adjustment ensures uniform and smooth feeding, avoids blockage of the main machine, and effectively improves the continuous and stable working time of the equipment. Stable structure and strong adaptability
Advanced hydraulic lubrication system: The main crusher lubrication system and hydraulic system are modularly designed and run independently, which can realize oil temperature, flow, pressure, power, abnormal power supply and other protections. Use of cone crushing station
Cone crusher is suitable for the crushing of raw materials in metallurgy, construction, road construction, chemical and silicate industries. According to different crushing principles and different product particle sizes, it is divided into many models. Crusher is widely used in many departments such as mining, smelting, building materials, highways, railways, water conservancy and chemical industries. Cone crusher has large crushing ratio, high efficiency, low energy consumption and uniform product particle size. It is suitable for medium and fine crushing of various ores and rocks.
