Product parameter table
Processing capacity 150-230t/h
Main engine power 250kw
Total power 297kw
Equipment size (length*width*height) 15800*3200*3000mm
Iron remover 4kw
Feed hopper 6kw
Main belt 15kw
Feed port size 1380*1000mm
Vibrating screen 6kw
Finished belt 7.5kw
Return material transition belt 3kw
Return material belt 5.5kw
Hopper volume 6m3
Total equipment weight 42t
Maximum feed size <650 (recommended)
Product parameter table
Product model ZQ-TV85G
Processing capacity 80-200t/h
Host power 220-440kw
Total power 242kw
Equipment size (length * width * height) 14500 * 3200 * 3700mm
Finished conveyor belt 11kw
Transfer feeder 11KW
600mm in feed inlet size
Hopper capacity 3m3
The total weight of the equipment is 30t
Maximum feed size<40mm (recommended)
Product parameter table
Standard: External power supply type is simple and efficient, with high reliability and low equipment maintenance and operation costs.
Product model QE-106G
Processing capacity 180-400t/h
Main engine power 110kw
Total power 135kw
Equipment size (length*width*height) 14500*3100*3600mm
Iron remover 4kw
Feed hopper 6kw
Main belt 15kw
Feed port size 1060*750mm
Feeding capacity 400/t
Hopper volume 6m3
Total equipment weight 32t
Maximum feed size <700mm (recommended)
Product parameter table
Product model QY-HP300G
Processing capacity 150-230t/h
Host power 250kw
Total power 298kw
Equipment size (length * width * height) 16800 * 3380 * 3680mm
Feed belt 11kw
Excessive material reflux of 3kw
Main belt 15kw
Feed inlet size 1078mm
Return belt 5.5hw
Finished belt 7.5hw
Hopper capacity 5m3
The total weight of the equipment is 42t
Vibration hanging screen 6kw
Maximum feed particle size<250mm (recommended)
