QS-1550 Number of sieve layers:2/3 sieve size:1520×5000mm sieve inclination angle:0-10° double amplitude:5-16mm maximum feeding size:300mm weight:4.3t motor power:2×11kw speed:750-100rpm
QS-1842 Number of sieve layers:2/3 sieve size:1820×4200mm sieve inclination angle:0-10° double amplitude:5-16mm maximum feeding size:300mm weight:4.5t motor power:2×11kw speed:750-100rpm
QS-1850 Number of sieve layers:2/3 sieve size:1820×6000mm sieve inclination angle:0-10° double amplitude:5-16mm maximum feeding size:300mm weight:5.1t motor power:2×11kw speed:750-100rpm
QS-2160 Number of sieve layers:2/3 sieve size:2120×6000mm sieve inclination angle:0-10° double amplitude:5-16mm maximum feeding size:300mm weight:6.6t motor power:2×11kw speed:750-100rpm
-
QF-1380 Maximum feeding edge length:700mm Processing capacity:150-230t/h Motor power:200-280kw Length x Width x Height:2900×2300×2860mm Weight (excluding motor):22.2t
QF-1313 Maximum feeding edge length:700mm Processing capacity:180-250t/h Motor power:250-315kw Length x Width x Height:3250×2300×2680mm Weight (excluding motor):23.5t
QF-1540 Maximum feeding edge length:800mm Processing capacity:180-350t/h Motor power:250-315kw Length x Width x Height:2900×2450×2860mm Weight (excluding motor):28t
-
QS-1548 Sieve layer: 2/3 Sieve size: 1500 x 4800mm Sieve inclination angle: 18-20 ° Double amplitude: 5-17mm Maximum feed size: 300mm Weight: 5.6T Motor power: 2 x 7.5kw Speed: 600-1100rpm
QS-6518 Sieve layer: 2/3 Sieve size: 1800 x 6000mm Sieve inclination angle: 18-20 ° Double amplitude: 5-17mm Maximum feed size: 300mm Weight: 7.4 Motor power: 2 x 7.5WU Speed: 600-1100rpm
QS-2160 Sieve layer: 2/3 Sieve size: 2100 x 6000mm Sieve inclination angle: 18-20 ° Double amplitude: 5-17mm Maximum feed size: 300mm Weight: 8T Motor power: 2 x 15kW Speed: 600-1100rpm
QS-2460 Sieve layer: 2/3 Sieve size: 2400 x 6000mm Sieve inclination angle: 18-20 ° Double amplitude: 5-17mm Maximum feed size: 300mm Weight: 9t Motor power: 2 x 15kW Speed: 600-1100rpm
-
QE-106 material trough size: 750 × 1060mm, discharge port adjustment range: 70.0-200mm, processing capacity: 52-208t/h, electromechanical power: 110kw double weight: 14-32t
QE-116 material chute size: 1100-4900mm Discharge port adjustment range: 100-200mm Processing capacity: 165-520t/h electromechanical power: 120-132kw Double weight: 19-41t
QE-120 material trough size: 1134-5900mm, discharge port adjustment range: 100-200mm, processing capacity: 140-304t/h, electromechanical power: 110-132kw, double weight: 26-57t
QE-130 materialchute size: 1500-6000mm, discharge port adjustment range: 100-250mm, processing capacity: 270-830t/h, electromechanical power: 110-160kw, double weight: 40-89t
-
QY-200 Dynamic cone diameter:940mm Maximum feeding force:132mm Processing capacity:90-250t/h Maximum recommended power:132kw Transmission shaft speed:700-1200rpm Weight:12.16t
QY-300 Dynamic cone diameter:1120mm Maximum feeding force:220mm Processing capacity:115-440t/h Maximum recommended power:220kw Transmission shaft speed:700-1200rpm Weight:18.1t
QY-400 Dynamic cone diameter:1320mm Maximum feeding force:275mm Processing capacity:140-630t/h Maximum recommended power:315kw Transmission shaft speed:700-1200rpm Weight:25.6
QY-500 Dynamic cone diameter:1520mm Maximum feeding force:315mm Processing capacity:175-790t/h Maximum recommended power:335kw Transmission shaft speed:700-950rpm Weight:37t
-
GS-1035 chute size: 1000-3450mm, maximum feed particle size: 450mm, processing capacity: 200-300mm, motor power: 15t/h, double amplitude: 4-10kw, weight: 3.5t
GS-1149 material trough size: 1100-4900mm, maximum feed particle size: 500mm, processing capacity: 300-400mm, motor power: 15t/h, double amplitude: 4-10kw, weight: 4.5t
GS-1159 material trough size: 1134-5900mm, maximum feed particle size: 550mm, processing capacity: 450-550mm, motor power: 22t/h, double amplitude: 4-10kw, weight: 5.35t
GS-1560 material trough size: 1500-6000mm, maximum feed particle size: 800mm, processing capacity: 600-800mm, motor power: 37t/h, double amplitude: 4-10kw, weight: 7.05t
